Name: MANITOWOC H Series Undercounter Ice Machines HDF0240A
Brand: Manitowoc
SKU: CFN-HDF0240A
Price: 10660.00 MYR
Availability: InStock

Features

SKU: CFN-HDF0240A

RM11,060.00

RM10,660.00

In Stock

Manitowoc · Model: HDF0240A

or /mo × months at 0% instalment

🚚 Free delivery (WM) 🔧 Installation included 🛡️ 2-year warranty 💬 WhatsApp support

Key Specifications

ModelHDF0240A

BrandManitowoc

Size (LxWxH) mm660.4 x 711.2 x 844

BTU2,400 (average), 3,400 (peak)

Voltage220-240V / 50Hz / 1 phase

Warranty Two Year Manufacturing Defect

OriginUnited States

Features

Angled door provides a larger opening making ice more visible and easier to accessIntelligence
Provides feedback with full bin and service indicators
Delay function allows you to pause your machine for slow periods or days when you’re closed
Smooth, sealed food-zone with removable water trough, distribution tube, and damper door for faster cleaning
Total height of machine is under 85cm with perfection for undercounter installation
Scoop holder can be installed on both left and right sides of bin
Air filter - simple, tool-free removal for quick access during routine cleaning and maintenance
Air flow - air in right, air out left, no side vents

Model	HDF0240A
Daily ice production	Up to 94 kg
Ice storage capacity	36 kg
Voltage	220-240V / 50Hz / 1 phase
BTU per hour	2,400 (average), 3,400 (peak)
Compressor	3/7 HP (Nominal rating)
Refrigerant	R404A
Ambient temperature range	40° to 110°F (4.4° to 43.3°C)
Water temperature range	45° to 90°F (4.4° to 32.2°C)
Water pressure (water in)	Minimum	20 psi (137.9 kPA)
	Maximum	80 psi (551.1 kPA)
Ice production 24 hours	21°Air / 10°C Water	85 kg
	32°Air / 21°C Water	66 kg
Power usage (100 lbs @ 32°C Air / 21°C Water)	8.23 kWh
Water usage (100 lbs of ice)	53.78 litres
Air-cooled total amps	3.5 amps
Maximum fuse size	Air-cooled and water-cooled	15 amps
	HACR-type circuit breakers can be used in place of fuses
Ice shape	Dice 22.2 x 22.2 x 22.2 mm
Dimension (L x W x H)	660.4 x 711.2 x 844 mm
