MIXER Spiral Mixer With 100L Fixed Bowl ASM 60 EVO
MIXER Spiral Mixer With 100L Fixed Bowl ASM 60 EVO
Features
- SKU
- FBE-ASM 60 EVO
RM51,390.00
RM47,000.00
Save to project
MIXER Spiral Mixer With 100L Fixed Bowl ASM 60 EVO
In Stock
Mixer · Model: ASM 60 EVO
or /mo × months at 0% instalment
🚚 Free delivery (WM)
🔧 Installation included
🛡️ 2-year warranty
💬 WhatsApp support
Key Specifications
ModelASM 60 EVO
BrandMixer
Size (LxWxH) mm635 x 1040 x 1360
Weight (KG)300
Capacity (ℓ)100
Warranty One Year Manufacturing Defect
OriginItaly
Features
- Painted steel structure raised from the ground on 4 adjustable feet
- Bowl, spiral, contrast column and guard made in stainless steel
- Two independent 2-speed motors for spiral and bowl
- Movement is trasmitted by pulleys and V-belts
- Bowl thrust roller
- Frontal control with two timers
- Setting of work time with automatic shift from 1st to 2nd speed
- Selector to reverse bowl
- Impulse button to rotate bowl for product removal
- Selector to activate second bowl speed
| Model | ASM 60 EVO | |
| Dough capacity | Minimum | 5 kg |
| Maximum | 60 kg | |
| Flour capacity | Minimum | 3 kg |
| Maximum | 38 kg | |
| Water capacity | Minimum | 2 litre |
| Maximum | 22 litre | |
| Bowl volume | 100 litre | |
| % water/flour minimum | 50% | |
| Spiral turns (50/60Hz) | 1st speed | 93 rpm |
| 2nd speed | 184 rpm | |
| Bowl turns (50/60Hz) | 1st speed | 10.5 rpm |
| 2nd speed | 21 rpm | |
| Motors power | 1st speed | 2.35 kW |
| 2nd speed | 3.25 kW | |
| Current drawn | 230V | 12 A |
| 400V | 7.8 A | |
| Spiral bar diameter | 30 mm | |
| Dimension (L x W x H) | 635 x 1040 x 1360 mm | |
| Net weight | 300 kg | |
